Description
Single line Brake proportioning valve. Fine thread tuning provides precise pressure adjustment. Used for street rods, pro series racing and off road vehicles.
Maximum Pressure Reduction    57%
Inlet/Outlet Ports              1/8-27 NPT
Mounting Hole Diameter         .250 inch
Mounting Hole Spacing          1.00 inch
Weight                       5.2 ounce
Also Available Brake Prop. Valve Fitting Kit (part# – 3120931354) In-line fitting kit for brake proportioning valve.
Install in front or rear brake line (whichever requires a reduction in the line pressure), with adjustment knob turned out away from housing to its full travel. This position is set at maximum reduction of line pressure (57%). After installation and brief track test, the adjustment knob may need to be altered to fine tune the brake bias. Turning the adjustment knob in towards the housing allows a graduated increase in line pressure to be released through the valve.
